Electric Bolt Lock LY-12

LY-12 Bolt lock adopt auto-control, special design according to the

voltage wave. It's working by power-on locking . The static current is 80mA only, belonging to nation’s lowest power waste for electric bolt lock. It has function of locking with magnetic force, strong anti-interrupt force, wide working voltage. And the lock body will not get hot with long-time service and  more safe to use.

Technical Parameter

Lock Size:203X34X40mm

Operating Voltage:10-24VDC

S ta rting Current:800mA

Constant Current:80mA

Type:Fail safe

Suitable for: wooden doors, glass doors, metal doors, fireproof doors

Delay Time:0,3,6,9S seconds adjustable

Signal output of lock state
